CWWK 12th generation N series 8-core new member Affordable version N305//N200/N100/fanless low power consumption micro mini industrial control host soft routing
Regular price
$210.78
Sale price
$189.70
Save $21.08
Product Features
1. Brand new lntel 12th generation N series full small core low power consumption processor
2. 1*SO-DIMM DDR5 memory 4800MHz compatible with 5200/5600MHz
3. 4*1ntel i226-V network card chip full UDE2.5G with filter connector
4. HDM12.1+DP1.4 dual display interface, support 4096 x 2160@60Hz
5. M.2 NVMe x4 high-speed interface can split multiple M.2 hard drives through the adapter board
6. M.2 WiFi slot supports Bluetooth/WiFi6 wireless receiving module
7. M.2 WiFi interface supports adapter board extension M.2 NVMe or mSATA SSD
8. The M.2 x4 interface supports the expansion of 2/3/4 M.2 NVMe x1 adapter boards
9. TF card holder supports data storage or system boot
10. 2*small 4PIN fan power supply sockets support temperature-controlled fans
Product parameters:
Processor: Intel N95 / Intel N100 / Intel N200 / Intel i3-N305
Memory: 1* SO-DIM DDR5 480OMHZ (compatible with 5200//5600MHz) maximum 32GB
Storage: 1*M.2 NVMe x4 (multiple M.2 or mSATA/SATA can be supported through the adapter board)
Graphics: Intel UHD Graphics
Display: HDMI2.1 supports 4096x2180@60Hz
DP1.4 supports 4096×2160@60Hz
Network card: 4*intel i226-V 2.5G network card
Wifi: 1*M.2 KEY-E (support Bluetooth/WiFi6 module)
USB: 4*USB2.0
Heat dissipation: fanless copper tube heat conduction aluminum shell passive heat dissipation
BIOS: AMI EFI BIOS supports self-starting when calling, GPIO, PXE network calling super
Power Consumption: 15W
Power supply: DC-12V5 (5*25 connector)
Chassis: aluminum alloy material
Extended pin header: 2*4Pin fan header with temperature control, 1*serial pin header, 1*USB pin header, 1*SW (shutdown USB pin header)
Expandable: M.2WiF supports expansion to NVMe/SATA/mSATA hard disk signals
M.2 X4 socket can expand 2/3/4 M.2x1
Size: 143.0mm (L) 135.6mm (W) X 40.0mm (H)
Color: Grey/Black
Installation method: desktop, wall-mounted (contact customer service for additional purchase)
Working environment: -0°C~t70'C relative temperature 5%-85%
